BACK SAVER SCOOTER LIFT
Model AWL-1600
The Bruno Back-Saver can ift and stow a folding manual wheelchair with Bruno’s Back-Saver. Roll a wheelchair on the platform, touch the button, and the wheelchair will be raised into place and automatically secured for travel. Designed to handle 16- and 22-inch wide folding manual wheelchairs with minimum 22-inch or wider wheels.
Lift Features
Specifications
- Lifting capacity: 100 lb/45 kg
- Vehicle compatibility: Go to MobilityMatcher
- Installed weight w/o Swing-Away: 50 lb/23 kg
- Installed weight w/Swing-Away: 87 lb/39 kg
- Hitch height: 9 in/23 cm to 18 in/46 cm
- Overall height: 43 in/109 cm
- Hitch type: Class I, II, III (receiver hitch required)
- 3-year limited warranty
Highlights
- Power up/down platform
- Self-locking securement
- Manual backup for peace of mind
- Potential to reinstall in another applicable vehicle
- Eligible for auto manufacturer potential rebates
All sales, installation and service provided by factory-authorized Bruno Dealer
Discover how Bruno Valet Signature Seating can complement your scooter/wheelchair lift
User Requirements
- Walk from front to rear of vehicle and vice versa
- Stand for two to three minutes
- Fold and unfold wheelchair
- Roll wheelchair on/off platform
- Turn key and hold down button
Video
Bruno Back-Saver™ | 1:42 min
Bruno mobility device lifts: Made in USA | 1:48 min
Brochures
